缸筒规格表
规格 公斤/米 规格 公斤/米 规格 公斤/米 规格 公斤/米
22/16 1.41 80/65 13.41 130/100 42.54 172/145 52.77
22/18 0.99 85/65 18.50 140/100 59.18 160/150 19.11
25/20 1.39 80/70 9.25 120/105 20.81 175/150 50.09
30/20 3.10 83/70 12.26 127/105 31.47 180/150 61.03
30/22 2.56 85/70 14.33 127/110 24.84 194/150 93.31
30/25 1.70 86/70 15.39 130/110 29.59 170/160 20.34
35/25 3.70 90/70 19.73 133/110 34.46 172/160 24.56
36/30 2.44 95/70 25.43 140/110 46.24 180/160 41.93
40/30 4.31 90/75 15.26 135/115 30.83 184/160 50.90
38/32 2.59 95/75 20.96 140/115 39.30 185/160 53.18
42/32 4.56 86/80 6.14 137/120 26.93 190/160 64.73
45/35 4.93 90/80 10.48 140/120 32.06 194/160 74.20
45/40 2.62 93/80 13.87 145/120 40.84 203/160 96.23
50/40 5.55 95/80 16.18 146/120 42.64 190/165 54.72
55/40 8.79 100/80 22.19 150/120 49.94 194/170 53.86
58/40 10.88 102/80 24.68 152/120 53.66 203/170 75.88
60/40 12.33 108/80 32.45 140/125 24.51 194/175 43.22
55/45 6.17 112/80 37.88 135/125 16.03 203/180 54.31
57/45 7.55 100/85 17.11 145/125 33.29 208/180 66.98
60/45 9.71 102/85 19.60 146/125 35.09 216/180 87.89
57/50 5.33 105/85 24.73 150/125 42.38 219/180 95.93
60/50 6.78 104/90 16.74 152/125 46.11 216/200 41.03
65/50 10.63 105/90 18.00 159/125 59.53 235/200 93.87
70/50 14.80 108/90 21.97 150/130 34.52 245/200 123.46
65/55 7.40 110/90 24.66 152/130 38.25 250/220 86.93
70/75 11.56 114/90 30.18 156/130 45.84 273/220 161.10
70/60 8.01 118/90 35.90 159/130 51.67 299/250 165.85
73/60 10.66 127/90 49.50 160/135 45.47 325/280 167.90
76/60 12.48 130/90 54.25 160/140 36.99 351/280 276.20
80/60 17.26 110/95 19.00 168/140 53.17 351/300 204.68 |
